PID Automatic Control Carbon Tube Furnace High Temperature For Purification

Product Details

Place of Origin: China

Brand Name: Jingtan

Certification: CE

Payment & Shipping Terms

Minimum Order Quantity: 1 set

Price: USD10,000-100,000/SET

Packaging Details: wooden case

Delivery Time: 60 days

Payment Terms: L/C/T/T

Supply Ability: 5pcs/month

Get Best Price

Contact Now

Specifications

Description

Specifications

Highlight:
                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                      High Temperature Carbon Tube Furnace, PID Automatic Control Carbon Tube Furnace, Carbon Tube Furnace For Purification


Place Of Origin:	Hunan, China	Type:	Resistance Furnace
Usage:	Purification Furnace	Video Outgoing-inspection:	Provided
Machinery Test Report:	Provided	Core Components:	PLC, Pressure Vessel, Pump, Cylinder
Brand Name:	Jingtan	Voltage:	380
Weight (t):	2 T	Power (kw):	120
Warranty:	1 Year	Key Selling Points:	Accurate Temperature Control
Limit Temperature:	2800℃	Voltage:	Three Phase 380v
Temperature Control Mode:	PID Automatic Control	Protective Gas:	Argon
Cooling Mode:	Circulating Water Cooling	Condition:	New
Warranty Of Core Components:	1 Year	Showroom Location:	Canada, Turkey, United Kingdom, United States, France, Germany, Saudi Arabia, Russia
Marketing Type:	New Product 2022	Applicable Industries:	Energy & Mining, Other, New Material

Place Of Origin:	Hunan, China
Type:	Resistance Furnace
Usage:	Purification Furnace
Video Outgoing-inspection:	Provided
Machinery Test Report:	Provided
Core Components:	PLC, Pressure Vessel, Pump, Cylinder
Brand Name:	Jingtan
Voltage:	380
Weight (t):	2 T
Power (kw):	120
Warranty:	1 Year
Key Selling Points:	Accurate Temperature Control
Limit Temperature:	2800℃
Voltage:	Three Phase 380v
Temperature Control Mode:	PID Automatic Control
Protective Gas:	Argon
Cooling Mode:	Circulating Water Cooling
Condition:	New
Warranty Of Core Components:	1 Year
Showroom Location:	Canada, Turkey, United Kingdom, United States, France, Germany, Saudi Arabia, Russia
Marketing Type:	New Product 2022
Applicable Industries:	Energy & Mining, Other, New Material

Description

PID Automatic Control Carbon Tube Furnace High Temperature For Purification

PID Automatic Control Fast Warming-Up Time Up To 200C/Hour High Carbon Tube Furnace For Purification

Product Description

High Temperature Carbon Tube Furnace
Mainly used for purification of graphite powder and other high temperature treatment. Its operating temperature can reach 2800℃, and can work continuously for a long time. Good production efficiency, energy saving. With on-line temperature measurement and temperature control system, the temperature in the furnace can be monitored in real time and adjusted automatically.

Model	JT-TGL-100	JT-TGL-150	JT-TGL-200
Operating Temperature	≤2400℃
Boat Size(mm)	φ100*320	φ150*400	φ200*420
Production Output(kg/d)	100	150	200
Protective Gas	argon
Temperature Control Mode	PID automatic control
Rated Power(kw)	80	150	180
Voltage(v)	three phase 380v
Temperature Measurement Mode	far-infrared measurement
Working Mode	push-boat type intermittent loading materials
Cooling Mode	circulating water cooling

(1)The temperature up to 2800 degree, good temperature uniformity, long constant temperature area, low failure rate of equipment operation.
(2) Long service life of furnace tube, continuous production 20-30 days with the furnace.
(3) With infrared temperature measurement and temperature control system, real-time display and PID automatic control, the product quality is stable.

(4) Adopt three-phase power supply mode,it is stable.
(5) Max. temperature 3000℃, it can work at 2600-2800℃ for a long time .

(6) Adopt automatic feeding device.
(7)The carbon felt as insulation material, it is convenient to change carbon tube, and it is clean.

(8) Push-boat production mode, continuous production.
(9) The material is in the boat, so it will not get pollution again.
(10) The product quantity of each boat is about 1.5 kg. Sample can be tested in time, and the process can be modified according to the test results.
(11) Short heating time, up to 200℃/ hour.
(12) Good sealing in furnace body, small loss of protective gas. All flanges and covers are sealed with sealing strips.
(13) The tank and flange of furnace body are made of stainless steel, without rust and with long service life.
(14) Equipped with a vacuum pump for the replacement of gas in the furnace, short ventilation time, less gas consumption.

Company Profile

Qualification and Patents

Production process

Customer Photos

Customer Cooperation Cases

Logistics System

FAQ

Are you a factory or trading company?

Q: Are you a factory or trading company?

A:Yes,we are China leading high-temperature vacuum furnace manufacturer 14+years,granted with many patent certifications in the domestic market.

Do you have customization or OEM service?

Q: Do you have customization or OEM service??

A:Yes,we have powerful R&D team and high-tech equipment.So we can not only supply the regular model,but also the customizable furnace as the repuirment of our clients.

What's your advantages?

Q:What's your advantages?

A:Quick response to your enquiry

High quality control

Stable supply chain in the domestic maket

Timely delivery

Excellent after-sales service,we can dispatch our engineer to the customer city for installation and debugging.
